| Storage Temperature Range | "-20°C to +60°C (4°F to 140°F) |
| SD Card Storage | 1 Micro SD slot, or use USB Dashmount Card reader MI10 with 2x Micro SD slots. max. 32Gb each. > 32 Gb format to NTFS |
| NMEA 2000 Connectivity | 1 x NMEA 2000 Micro-C port, 1 Len |
| Weight | 3.9 kg (8.6 lbs) |
| Operating Temperature Range | -15°C to +55°C (5° F to 131° F) |
| Dimensions W x H x D | 400.1 x 260 x 83 mm (15.75 x 10.24 x 3.27") With bracket: 474.9 x 307.5 x 222.5 mm (18.7 x 12.1 x 8.76") |
| Ethernet Ports | 3 x 100 Mbits/s ports, RJ 45. (Adapt to 5 pin yellow using adapter cable 000-11246-001) |
| Power Consumption max | 40 W +- 4 W |
| Recommended Fuse Rating | 6 A at 12 V DC |
| Waypoints, Routes, Tracks | 6000 waypoints, 500 Routes with 100 max route points, 50 tracks with up to 12,000 track points. |
| Supply Voltage | 10 - 32 V DC |
| Internal Storage | 16 GB |
| Digital Switching | BEP C-Zone, Naviop |
| Mounting Type | Panel or Bracket mount (use optional heavy duty bracket 000-13547-001 |
| Radar compatibility |
Halo, Broadband, HD Radars |
| Approvals Compliance | CE, C-Tick, HDMI, EN 60950-1:2006, EN 60945:2002 EN 300 440-2, V1.4.1 |
| Item Connectivity WiFi |
Internal 802.11b/g/n |
| Autopilot | Auto, Nav., No Drift, Follow up, Non-follow up, Turn patterns, Standby, Wind, Wind NAV. (Boat type set to Sail). Requires STBY button or Controller with STBY button to commission |
| NMEA 0183 Sentences supported | Input: GGA, GLL, GSA, GSV, VTG, ZDA, RMC, DBT, DPT, MTW, VLW, VHW, HDG, HDT, HDM, MWV, MWD, DSC, DSE, VDM. (Note AIS sentences are not bridged to or from NMEA 2000)Output: GGA, GLL, GSA, GSV, VTG, ZDA, RMC, DBT, DPT, MTW, VLW, VHW, HDG, MWV, MWD, TLL, TTM |
| Video | 2x composite video (BNC)1x high definition video (1080p, HDCP 1.4, HDMI-A)1x high definition video output (1080p, no HDCP, HDMI-A) |
| Charts supported | Insight, Navionics (Gold, NAV+ Platinum+) , C-MAP (MAX N, MAX N+) NV Digital (Raster US Charts) |
| Waterproofrating | IPX6 on the font (when panel mounted correctly with only the front exposed) Rear not waterproof |
| PC Connectivity | HDMI Video in from a PC |
| Bluetooth | Internal |
| Sonar Compatibility | External echo sounder module or connection to an MFD with built in echo sounder that can share sonar over Ethernet is required. |
| Display Resolution | 1920x1080 |
| AIS | Receive AIS data over NMEA 2000 Or NMEA 0183 (IAS is not bridged to N2K) |
| Weather | SiriusXM via WM-3 (USA only), GRIB |
| Languages | Standard Language Pack: English (US), English (UK), Danish, German, Spanish, Finnish, French, Greek, Icelandic, Italian, Dutch, Norwegian, Portuguese, Swedish. Other Language unlocksAsian Language Pack: English (US), Japanese, Korean, Thai, Chinese, Eastern European Language Pack: English (US), English (UK), Bulgarian, German, Spanish, French, Hebrew, Croatian, Hungarian, Italian, Lithuanian, Latvian, Polish, Slovak, Turkish/Russia/Ukraine Language pack: English (US), English (UK), German, Spanish, French, Italian, Russian, UkrainianMiddle Eastern Language Pack: English (US), English (UK), Arabic, German, Spanish, Farsi, French, Italian |
| Interface | Touch screen, OP40 or OP50 controller via NMEA 2000 |
| Manouevres Turn Patterns | U-turn, Spiral-turn, C-turn, Zig-zag, Square-turn, Lazy S-turn, Depth contour tracking |
| Multimedia | via SonicHub2, Fusion Link, Sirius, JL Audio. USA only, AUST. & NZ only) |
| Screen Brightness | 1200 nits |
| Display Size | 16 inches |
| Compass Safe | 50 cm (19.7") |
| Viewing Angles | 80° top/bottom, 80° left/right |
| Shock Vibration | CE, C-Tick, HDMI, EN 60950-1:2006, EN 60945:2002 EN 300 440-2, V1.4.1 |
| GPS | External GPS required |
| Time to First Fix | N/A |
| Correction | N/A |
| Position Accuracy | N/A |
| GPS Receiver Channels | N/A |
| Update rate | N/A |
| Backlight Color | White |
| Cartography included | World basemap |
| Steering Modes | Auto, Nav., No Drift, Follow up, Non-follow up, Turn patterns, Standby, Wind, Wind NAV. (Boat type set to Sail) |
