| Video and Audio |
| Image sensor | 1/2.8" Progressive CMOS |
| Resolution | - HD: 2560 x 1920
- SD: 1280 x 960
|
| Lens Types | Motorized, Vari-focal, Remote Focus |
| Focal Length | f = 2.7 ~ 13.5 mm |
| Aperture | F1.4 ~ F2.8 |
| Iris | P-iris |
| Field of View | - 95° ~ 30° (Horizontal)
- 70° ~ 23° (Vertical)
- 128° ~ 38° (Diagonal)
|
| Camera Movement | Pan: ±175° Tilt: 80° Rotate:±175° |
| Shutter Speed | 1/5 sec. to 1/32,000 sec. |
| Day/Night | Yes |
| IR Cut Filter | Yes |
| IR Range | 50 meters |
| Minimum Illumination | - 0.075 lux at F1.4 (Color)
- <0.01 lux at F1.4 (B/W)
- 0 lux with IR illumination on
|
| Onboard Storage | MicroSD/SDHC/SDXC card slot (Built-in 256GB industrial SDCard) |
| Standard video settings |
| Frame Rate | 15FPS |
| Video Streaming Settings | - HD Video 2560 x 1920 at 15fps 1.2Mbps upload
- SD Video 1280 x 960 at 15fps 300Kbps upload
|
| Standard audio settings |
| Audio | Two-way Audio |
| Interface | - External microphone Input
- External line output
|
| Analytics |
| Audio detection | Yes |
| Tampering detection | Yes |
| People Analytic | Intrusion detection, Line crossing detection, Loitering detection, Appearance Search, Scene Search, Re-Search, Profile Search |
| Vehicle Analytics | ntrusion detection, Line crossing detection, Loitering detection, Appearance Search, Scene Search, Re-Search |
| Object Analytics | Unattended object detection, Missing object detection |
| Power and Network |
| Power input | AC 24V/DC 12V, IEEE 802.3at PoE Class 4 (Power Redundancy) |
| Power Consumption | - PoE: MAX 22.5W / 18W (IR on/off)
- DC12V: MAX 23/ 18W (IR on/off)
- AC24V: MAX: 21W/16W (IR on/off)
|
| Connectivity | - RJ-45 cable connector for 10/100 Mbps PoE network connection
- Audio line input
- Audio line output
- DC 12V power input/AC 24V power input
- Digital input*2
- Digital output*1
|
| RTSP | WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, IPv6, NTP, QoS (CoS/DSCP), RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP |
| Users | - Up to 6 clients
- Live viewing for 6 clients
- Live viewing up to 4 clients and playback 2 clients
|
| Security | - Secure boot
- Signed firmware
- HTTPS/TLS encryption
- Video encryption
|
| Interface | - 10 Base-T/100 Base-TX Ethernet
- It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
|
| Hardware and Certification |
| General |
| Operating Temperature | Starting Temperature: -30°C ~ 60°C (-22°F ~ 140°F) |
| Working Temperature (IR on) | - -30°C~ 60°C (-22°F ~ 140°F) (IR Off)
- -40°C ~ 50°C(-40°F ~ 122°F) (IR On)
|
| Humidity | 90% RH (non-condensing) |
| Certifications | - EMC: CE (EN55032 Class A,EN55035), FCC (FCC Part 15 Subpart B Class A), ICES-003 issue 7,RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A)
- Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 62471,IEC/EN 60950-22);Environment; IK10 (IEC 62262), IP66 (IEC 60529)
|
| Included Accessories | Quick installation guide, alignment sticker, screw pack, cable gland |
| Mechanical Weight | 905g |
| Dimensions | O 155 x 104 mm |
| Body | Metal |
