Color:
Color: Stainless Steel

Features:

  • Compact size: Front panel is the size of a typical single gang midsize wall plate
  • Mounting: Flush mount in a single gang electrical box (2.25″" deep x 2.00″" wide x 2.84″" tall minimum) or surface mount in a Viking model VE-3x5 (not included, see DOD 424)
  • Faceplate Finish: #4 brushed stainless steel
  • PNL-VCAM-2-SS Replacement faceplate with matching screws available
  • Vandal Resistant Features:
    • 18 gauge 304 stainless steel faceplate
    • stainless steel camera mounting plate
    • scratch resistant powder coating
    • impact and scratch resistant camera lens
    • hex drive mounting screws
  • Weather Resistant Features:
    • Faceplate gasket
    • sealed camera lens
    • potted camera circuit board
    • stainless steel camera mounting hardware

Applications:

  • Door entry
  • Gate entry
  • Covert surveillance

Certifications:

  • EWP
  • IP66
  • FCC Part 15

The VCAM-2-BN is a compact, high resolution color composite video camera mounted behind a standard single gang wall plate. The VCAM-2-BN features an oil rubbed bronze faceplate. The extreme temperature rating and Enhanced Weather Protection make this camera ideal for mounting in outdoor locations

All cameras are equipped with Enhanced Weather Protection (EWP) for outdoor installations where the unit is exposed to precipitation or condensation. The VCAM-2-BN features sealed connections, as well as an epoxy potted circuit board.

For more information, please see pdf file User Manual

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews
Shipping Weight1.5 lbs (0.68 kg)
Dimensions4.875" x 3.125" x 1.0" (124mm x 79mm x 25mm)
Temperature-40°F to 185°F (-40°C to 85° C)
Humidity5% to 95% non-condensing
Image Sensor1/4" color CMOS
Video Output1VP-P composite, NTSC, 75 Ohms
Resolution420 lines (640 x 480 at 30fps / 307,200 pixels)
Sensitivity0.025 LUX (50 IRE) F1.2 3200K
Lens2.1mm, conical pinhole
Field of View80° Horizontal, 60° Vertical, 100° Diagonal
Tilt / Swivel AdjustmentVertical +/- 20°, horizontal +/- 30°
Connections(3) gel-filled butt connectors (3M Scotchlok UR2)

Volume discounts

We offer volume discounts for large orders.

Worldwide service

We ship all around the world. Our staff is experienced in export orders and worldwide shipping.

Member exclusive pricing

We also offer special prices for our regular customers.

Customer service from people who care

We have fast and friendly customer services. We care about your needs and will do our best to ensure your inquiries are taken care of.

Best products from the best manufacturers

We offer competitive prices on loads of products from leading manufacturers.
Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details
Shipping Weight1.5 lbs (0.68 kg)
Dimensions4.875" x 3.125" x 1.0" (124mm x 79mm x 25mm)
Temperature-40°F to 185°F (-40°C to 85° C)
Humidity5% to 95% non-condensing
Image Sensor1/4" color CMOS
Video Output1VP-P composite, NTSC, 75 Ohms
Resolution420 lines (640 x 480 at 30fps / 307,200 pixels)
Sensitivity0.025 LUX (50 IRE) F1.2 3200K
Lens2.1mm, conical pinhole
Field of View80° Horizontal, 60° Vertical, 100° Diagonal
Tilt / Swivel AdjustmentVertical +/- 20°, horizontal +/- 30°
Connections(3) gel-filled butt connectors (3M Scotchlok UR2)
