EVSP24VW Includes Only:

• 2x4 Video Wall Processor
• 5-pin Phoenix Connector
• (2) 3-pin Phoenix Connector
• RS232-Phoenix Connector Adapter Cable
• Digital Audio Optical Adapter
• 12V/3A Power Supply
• Mounting brackets and screws
• Product Manual

Features:

• 4K 2x4 HDMI Video Wall Processor
• Allows for 16 rows and columns of displays in any video wall configuration up to 16x16
• Two HDMI loop-outs to cascade into other units for larger video walls or to monitor sources locally
• Two HDMI inputs allow for multiple source video wall configurations, or to switch one source across the entire video wall display
• Passes up to 4K at60Hz with HDR
• Able to scale output resolutions
• HDMI 2.0 and HDCP 2.2 compliant
• Customizable options for bezel adjustment
• Supports 180° screen rotation
• Able to be controlled over RS232 and TCP/IP via product software or 3rd party control systems
• Dimensions: 8.5" W x 5.7" D x 1.7" H

The Evolution by Vanco EVSP24VW 4K Video Wall processor allows a source signal to be displayed across multiple displays to create a video wall. Equipped with two HDMI 2.0 inputs to connect multiple sources, with four outputs to create a video wall out of the box in multiple configurations. Need to create a larger video wall? Not a problem, the EVSP24VW features HDMI loop-outs to daisy-chain multiple units together up to a 16x16 configuration! Also features audio options including toslink digital audio output and balanced analog outputs, to break out into an amplifier or distributed audio system. Capable of passing 4K at60Hz with scaling, the EVSP24VW is the perfect video wall solutions for small and large applications.

For more information, please see Data Sheet and User Manual
